FIBER GLASS BATT PROFILE
The Canty system consists of a high resolution gigabit Ethernet camera sized to view the entire width of the BATT and angled to optimize the view of the profile. The camera is bracketed above the BATT and coupled with a laser(s) that help to define the profile of the BATT to the CantyVision Industrial Toolbox™ (CVIT) software. The images are brought in over CAT6 Ethernet cable to the Canty Vector Control Module™ (VCM) which hosts the CVIT software to allow for profile analysis and output to control system via OPC, 4-20mA or modbus.
Turbidity analysis using a high resolution CCD/CMOS image sensor that detects turbidity changes in fluids by measuring the transmittance of light. Using advanced software algorithms the system automatically removes gas bubbles from the analysis resulting in highly accurate and repeatable data outputs. This system is designed for inline use with varying pressures, temperatures, and pipe diameters.
