RTD temperature probes & Heat meters

Universal receiver for JUMO wireless measuring probes

The Wtrans receiver T01, in combination with suitable Wtrans transmitters, is used for the mobile or stationary measurement of the following physical measurands: temperature, pressure, and humidity. The wireless sensor technology also works in a harsh industrial environment.

Up to 4 analog outputs	No wiring work required	Customer-specific linearization

For thermocouples and RTD temperature probes

DIN EN 50446 defines the terminal head design types A and B, which differ in size and also slightly in their shape. Aluminum or plastic is used, depending on the application. These design types are suitable for the installation of a two-wire transmitter.

Various materials	Sealable versions	Installation of a transmitter

For thermocouples and RTD temperature probes

Screw-in thermowells are used for installing thermocouples and RTD temperature probes when replacement without draining the system and/or pressure resistance is required. Pressure stability is temperature dependent and specified in the data sheet.

Operating pressure up to 450 bar	Thermometers can be replaced without emptying the system	Low investment costs

With terminal head form B

Screw-in RTD temperature probes are predominantly used for measuring temperatures in liquids and gases. The installation type enables the formation of reliable seals for both vacuum and overpressure applications.

Single/double RTD temperature probe	Available with transmitter	Interchangeable measuring insert

With terminal head form J

Screw-in RTD temperature probes are predominantly used for measuring temperatures in liquids and gases. The installation type enables the formation of reliable seals for both vacuum and overpressure applications.

Single/double RTD temperature probe	Three-wire and four-wire circuit available	Transmitter available

With terminal head form B

Push-in RTD temperature probes are predominantly used for temperature measurement in liquid and gases. Application areas include air conditioning and refrigeration technology, process technology as well as heating, furnace, and apparatus engineering.

Single/double RTD temperature probe	Interchangeable measuring insert	Transmitter available

With terminal head form J

Push-in RTD temperature probes are predominantly used for temperature measurement in liquid and gases. The application areas are, among others, in air-conditioning and refrigeration technology as well heating, furnace, and apparatus engineering.

Single/double RTD temperature probe	Three-wire and four-wire circuit as an option	Transmitter available

Screw-in RTD temperature probe with/without transmitter

The product can be used in a wide range of industrial application areas. In particular for hygienic applications in the food and pharmaceutical industry. It consists of a protection tube with an integrated temperature sensor, a process connection, and an attached transmitter.

EHEDG certification	RoHS conformity for EU and China	Configuration via USB interface

Temperature sensor with IO-Link

The temperature sensor is equipped with an IO-Link interface that supports bidirectional communication (e.g. to exchange the process data, parameters, diagnostic information, and status messages) – ideal for connecting to automation systems in plant and mechanical engineering.

Process automation	Saves time during mounting/startup	Lower maintenance/repair costs

With connecting cable

Surface RTD temperature probes are used in closed pipe systems or on other round and flat surfaces. The probes can be installed with ease using tightening bands or cable ties, which means that mechanical modification of the measuring location is not necessary.

Simple and quick installation	Various materials	Low thermal mass

With connecting cable according to DIN EN 60751

Due to their specific features, ATEX/IECEx RTD temperature probes with connecting cables are used in pharmaceutical and chemical plants, power plants, pipes, on test rigs, in engine manufacturing, and at any measuring locations requiring flexibility and simple replacement.

Two-wire, three-wire, or four-wire circuit	Shielded connecting cables	Single, double, and triple variant

RTD temperature probes for process technology with Ex approval

RTD temperature probes for process technology are predominantly used for temperature measurement in liquids and gases. They consist of a protection fitting according to DIN 43772 with various process connections, a terminal head, and an interchangeable measuring insert.

Interchangeable measuring insert	Stainless steel/ titanium/tantalum/ Inconel®/HASTELLOY®	Two-wire transmitter available

With connecting cable

Screw-in RTD temperature probes with connecting cable are used in such fields as air-conditioning and refrigeration technology, heating and furnace construction, and apparatus engineering.

Single/double RTD temperature probe	PVC, silicone, PTFE, metal braiding	Optionally with bend protection

Screw-in RTD temperature probe for marine applications

The screw-in RTD temperature probe is the preferred choice for measuring temperatures in liquid and gaseous media in the shipping industry. A decisive criterion is the reliable sealing feature when vacuum and overpressure occurs. This is how it is certified according to Bureau Veritas.

Bureau Veritas certified	Up to 100 °C ambient temperature	Sealing feature when vacuum and overpressure occurs

RTD temperature probe with wireless data transmission

The thermometer acquires temperatures in the operating range from -30 to +260 °C or -200 to +600 °C. This measured value is transferred wirelessly to the receiver of the Wtrans measuring system. This makes it ideal for mobile or stationary temperature measurement without any wiring work.

No wiring work required	Fail-safe transmission	Available with ATEX approval

For temperature measurement in grain silos

The multipoint temperature probe reliably measures the temperature at different heights of a silo. The RTD temperature probe can be used for concrete and metal silos. Depending on the version, the multipoint temperature probe can be mounted outside or inside.

Up to 64 measuring points	Sturdy industrial version	ATEX approval

RTD temperature probe with CANopen output

RTD temperature probes are predominantly used for temperature measurement in liquids and gases. Areas of application include medical technology, mechanical engineering, drive technology, commercial vehicles, and railroad systems.

Vibration-resistant construction	Limit value monitoring function	Single/double RTD temperature probe

For indoors, walls, and outside

Indoor, wall, and outdoor RTD temperature probes for air conditioning technology are mainly used to measure temperature in rooms, halls, and outdoors. Various device versions made of plastic with different protection types are available for the respective measuring task.

Two-wire, three-wire, or four-wire circuit	Analog transmitter available	SIL and PL compatible

For the food and pharmaceutical industry

The RTD temperature probes can be built with terminal heads made of either stainless steel, aluminum die-cast, or plastic. Various process connections are available for the different requirements of sub-areas in the food and pharmaceutical industry.

Hygienic process connections	CIP-compliant installation	Two-wire transmitter available

Wheelset temperature probe

JUMO railTEMP has a qualified measuring insert especially developed for railway applications with up to 2 sensing elements and can be equipped with different sensors. The firmly attached connection line is available with a variety of different connections or high-quality connectors. Halogen-free materials and cable protection ensure maximum safety in rail transport as well as reliable measurement results.

Certified acc. to DIN EN 50155/61373	Vibration and shock-resistant	Flexible sensor technology

Screw-in RTD temperature probe with plug connector

The screw-in RTD temperature probes of the VIBROtemp series are reliable –even under pressure– at measuring the correct temperature in commercial vehicles, construction machinery, agricultural machinery, motors, compressors, and in many areas from the railway technology field. Use in hydrogen applications is possible. Different plug connections are available to suit the specific application area.

Locked to ensure contact	Vibration-resistant construction	Long-term stability

Screw-in RTD temperature probe for combined cold and heat meters for direct mounting (type DS/DL)

Combined cold/heat meter RTD temperature probes are used for temperature measurement in closed pipeline systems. Direct mounting without an additional thermowell is recommended to achieve optimum thermal coupling to the measurement medium in the heating system.

Certified according to module D (MID)	DIN EN 1434, AGFW FW 202, and FW 211	Conformity according to the German MessEG and MID

Screw-in RTD temperature probe for heat meters with terminal head for direct mounting (type DL)

These type DL heat and cold meter RTD temperature probes are used for temperature measurement in closed pipeline systems. Direct mounting without an additional immersion sleeve is recommended to achieve optimum thermal coupling to the measurement medium in the heating system.

Certified according to module D (MID/MessEV)	DIN EN 1434, AGFW 202, and FW 211	Conformity according to the German MessEG/MID

Screw-in RTD temperature probe for combined cold/heat meters with terminal head for direct mounting (type DL)

Combined cold/heat meter RTD temperature probes are used for temperature measurement in closed pipeline systems. Direct mounting without an additional thermowell is recommended to achieve optimum thermal coupling to the measurement medium in the heating system.

Certified according to module D (MID)	DIN EN 1434, AGFW FW 202, and FW 211	Conformity according to the German MessEG and MID

Push-in RTD temperature probe for heat meters with connecting cable for thermowells (type PS/PL)

RTD temperature probes for heat meters are used for temperature measurement in closed pipeline systems. As the probes are installed in thermowells, emptying the system for regular replacement at the end of the certification period is no longer necessary.

Pairing and conformity according to MID	Type examination certificate available	DIN EN 1434, AGFW FW 202, and FW 211

For heat meter temperature probes

Thermowells are used for replacement of the RTD temperature probes without emptying the system and/or pressure resistance. Shorter thermowells are mostly screwed into T-pieces while longer design types are screwed into special welded sockets or welded directly in the pipe wall.

MID-compliant with identification marking	Various materials	Available with inspection certificate 3.1

For devices and plants tested according to DIN EN 14597

Screw-in thermocouples are predominantly used for measuring temperature in liquids and gases. Protection tubes made of various materials protect the measuring insert against chemical influences and mechanical damage.

Single or double thermocouple	Use in plants according to DIN 4754	For the media water, oil, or air

Food insertion thermocouples

Due to their special construction, these robust, steam-tight food insertion thermocouples are especially suited to cooking, boiling, and baking processes in all food processing and food preservation applications. The stainless steel probe tube is available with a concentric or oblique probe tip.

Steam-tight	High mechanical strength	Multiple measuring points

Head transmitter with wireless data transmission

The wireless transmitter measures temperature and other process variables. The compact design type of the aerial battery housing allows for simple installation on type B DIN terminal head.

User configurable PC setup program	Stationary and mobile measurements	Fail-safe transmission

Mobile access to JUMO devices

The JUMO Device App provides the user with mobile access to their process data at all times. All current process values as well as the alarm and event list from selected JUMO devices which are networked via Ethernet can be viewed in text form.

Display of current process values	App for Android and iOS systems	Mobile access to JUMO devices
