Surface RTD temperature probes
With connecting cable
Surface RTD temperature probes are used in closed pipe systems or on other round and flat surfaces. The probes can be installed with ease using tightening bands or cable ties, which means that mechanical modification of the measuring location is not necessary.
 |
 |
 |
|
Simple and
quick installation |
Various materials
|
Low thermal
mass |
GENERAL TECHNICAL DATA |
| Special features | Including installation kit |
| Process connection | Screw, tightening band |
| Protection fitting | Stainless steel 1.4571, aluminum |
| Protection type | IP65 |
| Areas of application | Packing machines, pipeline construction, plant engineering |
| Option | Bend protection |
| Operating temperature | -50 to +260 °C |
| Features | Low thermal mass for round and flat surfaces |
| Sensor | Pt100, Pt500, Pt1000 |
| Connection | Tin-plated connection wires, ferrules according to DIN 46228 Part 4 (standard), plug-in sleeve 6.3 according to DIN 46247 |
| Measuring circuits | 1 |
| Connecting cable | PVC, silicone, PTFE, stainless steel PTFE |
Universal receiver for JUMO wireless measuring probes
The Wtrans receiver T01, in combination with suitable Wtrans transmitters, is used for the mobile or stationary measurement of the following physical measurands: temperature, pressure, and humidity. The wireless sensor technology also works in a harsh industrial environment.
 |
|
 |
|
Up to 4 analog
outputs |
No wiring work
required |
Customer-specific
linearization |
For thermocouples and RTD temperature probes
DIN EN 50446 defines the terminal head design types A and B, which differ in size and also slightly in their shape. Aluminum or plastic is used, depending on the application. These design types are suitable for the installation of a two-wire transmitter.
|
 |
 |
|
Various
materials |
Sealable versions
|
Installation of
a transmitter |
For thermocouples and RTD temperature probes
Screw-in thermowells are used for installing thermocouples and RTD temperature probes when replacement without draining the system and/or pressure resistance is required. Pressure stability is temperature dependent and specified in the data sheet.
|
 |
 |
|
Operating pressure
up to 450 bar |
Thermometers can
be replaced without emptying the system |
Low investment
costs |
