SOLITRAC 31

Radiometric sensor for continuous level measurement

Rod detector

Introduction Application Technical specifications Documentation

Application area

SOLITRAC 31 is ideal for use on cylindrical vessels, reactors, autoclaves, separators and mixing vessels. SOLITRAC offers extraordinarily high accuracy over the entire measuring range.

The SOLITRAC 31 is a radiation-based sensor with PVT rod detector for continuous measurement of liquids and bulk solids. It is suitable for level measurement under extreme process conditions, with critical product features or in aggressive products. The SOLITRAC 31 is ideal for use in cylindrical vessels, reactors, autoclaves, separators and mixing vessels.

Your benefit

Best measurement performance through PVT detector with maximum sensitivity
Simple mounting through supplied accessory
High plant availability through non-contact measurement

Other applications

Measuring range - Distance	3 m [Meter - Foot]
Process temperature	- [°C - °F]
Process pressure	- [Bar - kPa - psi]
Accuracy	± 0.5 %
Materials, wetted parts	No wetted material
Seal material	no media contact
Housing material	Aluminium Stainless steel (precision casting)
Protection rating	IP66/IP67
Output	Profibus PA Foundation Fieldbus Four-wire: 4 … 20 mA/HART
Ambient temperature	-40 ... 60 °C

Scope	ATEX / Europe CSA / Canada FM / USA EAC (GOST) / Russia IEC / worldwide NEPSI / China INMETRO / Brazil
Explosion protection	Intrinsic safety "i" Flameproof enclosure "d" Dust ignition protection "t"
Overfill protection	WHG
SIL qualification	SIL2

Adjustment	PLICSCOM PC, PACTware and DTM HART-Communicator Software (e. g. AMS™, PDM)
Indication	Display/adjustment module PLICSCOM VEGADIS 81 VEGADIS 82
