Platinum temperature sensors Pt100, Pt1000

With solderable terminal clamps and epoxy protective coating according to DIN EN IEC 60751

Platinum-chip temperature sensors of the PCWC design type are especially suited for various probes in the heating, ventilation, and air-conditioning industry; the temperature sensor may also be openly positioned in the air flow with nothing surrounding it. The sensors are available as Pt100 and Pt1000.

Protection against moisture and condensation	Solderable connection terminals	High measuring accuracy

With connection wires according to DIN EN IEC 60751

Platinum chip temperature sensors of the PCWR design type belong to the category of temperature sensors that were made using thin-film technology. The sensors have connection wires extending to the center of the sensor and are suitable for confined spaces. The sensors are available as Pt100 and Pt1000.

For confined spaces	High measuring accuracy	High long-term stability

With connecting wires and metallized back cover according to DIN EN IEC 60751

Platinum chip temperature sensors of the PCWRB design type belong to the category of temperature sensors that were made using thin-film technology. The sensors are equipped with a solderable nickel-gold metallization on the back cover. The metal layer enables direct thermal contact with another body via a solder connection.

Solderable metallized back cover	For confined spaces	High measuring accuracy

In SMD design type according to DIN EN IEC 60751

Platinum-chip temperature sensors belong to the category of thin-film technology temperature sensors. Sensors of the SMDFC design type have a single-sided contact for "face down mounting" (flip chip). The sensors are available as Pt100, Pt500, and Pt1000.

AEC-Q200 for selected sensors	For automatic placement	SMD sizes 0805 and 1206

In SMD design type (flip chip) with metallized back cover according to DIN EN IEC 60751

Platinum chip temperature sensors belong to the category of temperature sensors that were made using thin-film technology. Sensors of the SMDFCB design type have a single-sided contact (flip chip) and are equipped with a solderable nickel-gold metallization on the back cover. The metal layer enables direct thermal contact with another body via a solder connection.

Solderable metallized back cover	For confined spaces	SMD size SMD 0805

With connection wires according to DIN EN IEC 60751

Platinum chip temperature sensors of the PCW design type belong to the category of temperature sensors that were made using thin-film technology. They are typically used in the following industries: heating engineering, air conditioning technology, ventilation technology, industrial technology, medical and laboratory engineering, white goods, mechanical engineering, and motor and commercial vehicles. The sensors are available as Pt100, Pt500, Pt1000.

High long-term stability	Standardized nominal values and tolerances	High measuring accuracy

With connection wires according to DIN EN IEC 60751

Platinum chip temperature sensors of the PCW design type belong to the category of temperature sensors that were made using thin-film technology. They are typically used in the following industries: heating engineering, air conditioning technology, ventilation technology, industrial technology, medical and laboratory engineering, white goods, mechanical engineering, and motor and commercial vehicles. The sensors are available as Pt100 and Pt1000.

For high operating temperatures	High measuring accuracy	High long-term stability

In SMD design type according to DIN EN IEC 60751

Platinum-chip temperature sensors belong to the category of thin-film technology temperature sensors. For example, they are frequently applied in temperature monitoring or compensation circuits, as well as an array of applications in temperature probes. The sensors are available as Pt100, Pt500, and Pt1000.

For automatic placement	SMD sizes 0805 and 1206	AEC-Q200 for selected sensors

With connection wires according to DIN EN IEC 60751

Platinum chip temperature sensors of the PCW design type belong to the category of temperature sensors that were made using thin-film technology. They are typically used in the following industries: heating engineering, air conditioning technology, ventilation technology, industrial technology, medical and laboratory engineering, white goods, mechanical engineering, and motor and commercial vehicles. The sensors are available as Pt100, Pt500, Pt1000.

High measuring accuracy	High long-term stability	Standardized nominal values and tolerances

With connection wires according to DIN EN IEC 60751

Platinum chip temperature sensors of the PCW design type belong to the category of temperature sensors that were made using thin-film technology. They are typically used in the following industries: heating engineering, air conditioning technology, ventilation technology, industrial technology, medical and laboratory engineering, white goods, mechanical engineering, and motor and commercial vehicles. The sensors are available as Pt100, Pt500, Pt1000.

High measuring accuracy	High long-term stability	Standardized nominal values and tolerances

With platinum chip temperature sensors of SMD design type according to DIN EN 60 751

Temperature sensors of the PCB-B-Au design type are pre-assembled measuring inserts, which are equipped with platinum chip temperature sensors in SMD design type. The circuit board is connected via gold-plated solder contacts.

Pre-assembled	For the assembly of simple temperature probes	Available in large quantities at low cost
