Flow
The product range for flow measurement technology includes devices with features just as versatile as their applications. In addition to electromagnetic flowmeters the JUMO product range includes paddlewheel and flow sensors as well as differential pressure transmitters. The right solution is avaible for every application whether you want to measure the flow of gases, liquids, or sludges.
Precision flow measurement for continuous monitoring and controlling
JUMO helps you safely design your process technology with sensors known for their long-term stability and precision. Depending on the application, we can offer you the right flowmeters for liquids, gases, or vapors. If adjusted to the corresponding evaluation devices and controllers, the devices allow the flow to be measured, displayed, controlled, or recorded.
The JUMO product range comprises a wide range of devices. Orifice plates and Pitot probes offer the greatest device variety. When these are combined with differential pressure transmitters they also provide the best measuring accuracy.
We offer both electromagnetic and ultrasonic flowmeters specifically for flow measurements in liquids. The magnetic-inductive devices were developed for industrial and hygienic applications. They are particularly flexible and available with a large variety of nominal widths, measuring tube linings, materials, and process connections.
While the magnetic-inductive measuring method requires conductivity, ultrasonic devices also measure the flow of non-conductive media such as ultra-pure water. Our ultrasonic sensors can even be used with corrosive media thanks to their tube being made of high-performance plastic and a wide range of nominal widths.
For flow sensors
With the assistance of the fittings, the push-in devices MID flow transmitter (type 406010 & 406011) and the paddlewheel flow sensor (type 406020) are integrated into the pipe. In addition to the T-fittings for screw connection, welded sockets and pipe clamps are available.
 |
 |
 |
|
Process connections
DN 15 to DN 400 |
Choice between plastic
and stainless steel |
Minimal installation
effort |
Plug-in magnetic-inductive flow transmitter
The transmitter can be used in liquids with a conductivity as of 20 μS/cm. Standardized fittings ensure simple insertion of the transmitter into pipes from DN 15 to DN 400. The output signal is 4 to 20 mA and the pulse frequency signal is 0 to 240 Hz.
|
Minimal
installation effort |
 |
 |
|
Configurable
switching outputs |
Standardized
fittings |
Plug-in paddlewheel flow sensor
The product continuously measures the flow velocity of neutral or slightly aggressive liquids that have low solid content Flow velocities of 0.3 to 10 m/s can be measured. The measured value appears as a pulse frequency.
|
Minimal
installation effort |
 |
 |
|
Standardized
fittings |
Low investment
costs |
Flow measurement with orifice plate
The flow measurement based on the differential pressure is universal and can be used in liquids, gases, and steam. The JUMO flowTRANS DP R primary element can be used within a wide range of nominal widths, temperatures, and pressures.
|
|
 |
|
Low-resistance
UW glass |
Quick measurement
results |
Low investment
costs |
Flow measurement with pitot tube
The flow measurement based on the differential pressure is universal and can be used in liquids, gases, and steam. The JUMO flowTRANS DP P primary element can be used within a wide range of nominal widths, temperatures, and pressures.
|
 |
|
|
Low pressure
loss |
Short inlet and
outlet sections |
For extreme
pressures and temperatures |
Ultrasonic flowmeter
Absolut wear and maintenance-free ultrasonic technology allows the flowmeter to measure with high precision and independent of the conductivity. It can also be extended with temperature and pressure sensors. The device can be integrated into sensor networks via JUMO digiLine or IO-Link interface. Configuration is convenient via Bluetooth and app.
 |
 |
|
|
Temperature and
pressure measurement possible |
Precise
measurement |
Wear and
maintenance free |
Electromagnetic flowmeter
The JUMO flowTRANS MAG H20 is an electromagnetic flowmeter for industrial automation. Its compact design allows it to fit into the smallest plants (dosing systems, apparatus cooling) and to measure conductive media with a high degree of precision. TRI-Clamps allow process-oriented use in the hygienic industry. The usual G-type external threads are available as well.
|
 |
 |
|
Measurement of
small quantities |
Compact design
|
Modern HMI
|
Electromagnetic flowmeter
The OPTIFLUX 6000 is an electromagnetic flowmeter (EMF) for hygienic applications in the food sector. The 3A and EHEDG certified flowmeter has industry-specific insertion lengths to meet the stringent requirements of the food and beverage industry.
 |
|
 |
|
3A, EHEDG, FDA &
EC1935/2004 compliant |
Opt. stainless steel
case/separated/compact |
Extensive error
diagnostics |
Electromagnetic flowmeter
The electromagnetic flowmeter OPTIFLUX 1000 can be used to measure conductive liquids in pipes with nominal widths from DN 10 to DN 150. The device has been designed for standard industrial applications and can be used in liquid media with different properties.
 |
|
 |
|
Space-saving
installation |
Wear and
maintenance free |
Wide dynamic
measuring range |
Ultrasonic flowmeter for liquids
The flowmeter measures precisely in conductive and non-conductive media. Ultrasonic technology allows it to be absolutely free of wear and maintenance. Its metal-free housing and the plastic pipe in various nominal widths allow it to be used in a flexible manner – even when dealing with corrosive media.
|
|
 |
|
Precise
measurement |
Low wear and
low maintenance |
Flexible in its
application |
Plug-in magnetic-inductive flow transmitter with display
The transmitter can be used in liquids with a conductivity as of 20 μS/cm. Standardized fittings ensure simple insertion of the transmitter into pipes from DN 15 to DN 400. The output signal is 4 to 20 mA and the pulse frequency signal is 0 to 240 Hz.
|
|
Minimal installation
effort |
|
High degree of
functionality |
Illuminated LCD
display |
Mobile access to JUMO devices
The JUMO Device App provides the user with mobile access to their process data at all times. All current process values as well as the alarm and event list from selected JUMO devices which are networked via Ethernet can be viewed in text form.
 |
|
 |
|
Display of
current process values |
App for Android
and iOS systems |
Mobile access to
JUMO devices |
